Broadcom PCI Interface IC | Part #PCI9656-BA66BI G | Integrated Circuit | DEX

The PCI 9656 offers flexible connectivity and high performance I/O acceleration features to enable leading edge PCI, CompactPCI and embedded host designs.

Connectivity:

• 64-bit, 66MHz PCI r22 compliant
• Motorola PowerQUICC and generic 32-bit, 66MHz local bus modes
• 3.3V I/O, 5V tolerant bus interfaces
• PICMG 2.1 r20 Hot Swap Silicon
• 272-ball, 27 x 27 mm, 1.27 mm pitch PBGA

Performance:

• Zero wait state burst operation
• PCI bus bursts to 528 MB/sec
• Local bus bursts to 264 MB/sec
• 2 DMA Channels
• Block and Scatter/Gather transfers DMA descriptor ring management
• Demand Mode and EOT Hardware controls
• Direct Salve data transfers
• Access 8-, 16-, and 32-bit local bus devices
• Deferred reads, deferred writes, read ahead, posted writes, programmable read prefetch counter

BRM:PCI9656-BA66BI G

PCI9656-BA66BI G
