The ExpressLane PEX 8732 device offers Multi-Host PCI Express switching capability enabling users to connect multiple hosts to their respective endpoints via scalable, high bandwidth, non-blocking interconnection to a wide variety of applications including servers, storage, communications, and graphics platforms. The PEX 8732 is well suited for fan-out, aggregation, and peer-to-peer traffic patterns.

Highlights

• 32-lane, 8-port PCIe Gen 3 switch
• Integrate 8.0 GT/s 8.0 GT/s SerDes d
• 27 x 27mm2, 676-pin FCBGA package 27 x 27mm2
• 676-pin FCBGA package
• Typical Power: 6.0 Watts

Key Features

• Standards Compliant
• PCI Express Base Specification, r3.0
• Compatible w/ PCIe r1.0a/1.1 & 2.0ec, r1.2
• Compatible w/ PCIe r1.0a/1.1 & 2.0
• PCI Power Management Sp
• Microsoft Vista Compliant
• Supports Access Control Services
• Dynamic link-width control
• Dynamic SerDes speed control
