Microchip Technology IC Opamp G 1 Circuit Amplifier Part #MCP6H91T-E/MNY

Microchip’s MCP6H91/2/4 family of operational amplifiers (op amps) has a wide supply voltage range of 3.5V to 12V and rail-to-rail output operation. This family is unity gain stable and has a gain bandwidth product of 10 MHz (typical). These devices operate with a single-supply voltage as high as 12V, while only drawing 2 mA/amplifier (typical) of quiescent current. The MCP6H91/2/4 family is offered in single (MCP6H91), dual (MCP6H92) and quad (MCP6H94) configurations. All devices are fully specified in extended temperature range from -40°C to +125°C.

Features

• Input Offset Voltage: ±1 mV (typical)
• Quiescent Current: 2 mA (typical)
• Common Mode Rejection Ratio: 98 dB (typical)
• Power Supply Rejection Ratio: 94 dB (typical)
• Rail-to-Rail Output
• Supply Voltage Range:
• Single-Supply Operation: 3.5V to 12V
• Dual-Supply Operation: ±1.75V to ±6V
• Gain Bandwidth Product: 10 MHz (typical)
• Slew Rate: 10 V/µs (typical)
• Unity Gain Stable
• Extended Temperature Range: -40°C to +125°C
• No Phase Reversal

Applications

• Automotive Power Electronics • Industrial Control Equipment
• Battery Powered Systems
• Medical Diagnostic Instruments

MCH:MCP6H91T-E/MNY

MCP6H91T-E/MNY
