NXP Semiconductors IC Supervisor 3 Channel Part #DS1830AS+T&R | IC | DEX

The DS1830 Reset Sequencer monitors the power supply for an in-tolerance condition and the pushbutton reset input for a manual reset. First a precision temperature-compensated reference and comparator circuit monitors the status of the power supply and when an out-of-tolerance condition is detected, an internal power fail signal is generated that forces the reset lines to go to an active state. If the power supply returns to an in-tolerance condition, RST1 will release followed by RST2 and finally RST3 . Sequencing of resets allows for systems to power-up in an orderly manner providing superior reliability.

Features:

• 5V (DS1830) or 3.3V (DS1830A) power-on reset
• Excellent for systems that need power-on resets in a consistent sequence
• Asserts resets during power transients
• Pushbutton reset input for system override
• Selectable reset timing
• Reduces need for discrete components
• Precision temperature-compensated voltage reference
• 8-pin DIP, 8-pin SO, or space saving 8-pin µSOP
• Operating temperature of -40°C to +85°C
• Open-drain, active-low inputs

NXP:DS1830AS+T&R

DS1830AS+T&R
