Onsemi Multi-Output Power Management IC (PMIC) for Safety Applications Part #NCV97200 | IC | DEX

The NCV97200 is a 2-output monolithic regulator consisting of 1 buck regulator and 1 boost regulator with supervisory functions including window voltage monitoring on all outputs and a window watchdog. This product is ideal for ADAS (Advanced Driver Assistance Systems) applications and utilizes an independent voltage reference and an adjustable independent oscillator to realize the supervisory features. A 40 V non-synchronous buck regulator converts the battery supply voltage to a 3.3 V output, and delivers up to3 A (peak). This output rail may be used as the low voltage input voltage for the non-synchronous secondary boost converter. The secondary boost is fixed and is intended to supply a low current 5.0 V rail for In-Vehicle Networking circuits (IVN). All internal MOSFETs are N-channel devices, and a bootstrap circuit is used to drive the buck high-side MOSFET. Both SMPS outputs use peak current mode control with internal slope compensation. The IC incorporates an internal regulator that supplies charge to the low-voltage gate drivers. The NCV97200 is a functional safety solution that reduces the time required to develop safety systems that comply with the International Standards Organization (ISO) 26262. The device includes a range of integrated safety features such as dedicated feedback references, output voltage monitoring, and window watchdog.

Features

• 1 Enabled Buck Converter
• 1 Boost Converter for IVN Supply
• Wide Input of 4.1 to 40 V with Undervoltage Lockout (UVLO)
• Fixed Frequency Operation at 2 MHz
• Window Watchdog with Independent References
• Cycle-by-cycle Current Limit Protection
• External Frequency Synchronization
• Pseudo-random Spread Spectrum for Improved EMI•QFN Package with Wettable Flanks (pin edge plating)
• NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC-Q100 Qualified and PPAP Capable

Applications

• Safety Applications
• ADAS (Advanced Driver Assistance Systems)
• Body Electronics
• Telematics

End Products

• Automotive
