Onsemi System basis Chip Evaluation Board Part #NCV7535VMFD5C466GEVB | Evaluation Board | DEX

The NCV7535VMFD5C466NGEVB is designed to quickly evaluate the NCV7535 H-bridge pre-driver. The design demonstrates a full application incorporating: Dual SO8FL MOSFETs, a microcontroller, 5 V voltage regulator, current-sense amplifier, controls and USB interface. The board is intended to provide quick and convenient means for evaluation of NCV7535 application either standalone, controlled from a PC or by an external microcontroller.

Features

• High Current, Low VCE(sat), ESD Robust, High Current Gain, High Cut Off Frequency, Low Profile Package, Linear Gain (Beta)

Benefits

• Improved Circuit Efficiency, Decreased Battery Charge Time, Reduce component count, High Frequency Switching, Smaller Portable Product, No distortion

Applications

• Load Switching, Battery Charging, External Pass Transistor, DC/DC Converter, Complimentary Driver, Current Extension & Low Drop Out Regulation, Cathode Florescent Lamp drive, Peripheral Driver - LEDs, Motors, Relays

ONS:NCV7535VMFD5C466GEVB

NCV7535VMFD5C466GEVB
