Taiwan Semiconductor Manufacturing, part # BYG20D R3 has these features: Glass passivated junction chip. For surface mounted application Low forward voltage drop Low profile package Built-in stain relief, ideal for automatic placement Fast switching for high efficiency High temperature soldering: 260℃/10 seconds at terminals Plastic material used carries Underwriters Laboratory Classification 94V-0 Meet MSL level 1, per J-STD-020D, lead free maximum peak of 260℃ 94V-0 Green compound with suffix "G" on packing code & prefix "G" on datecode
Mechanical Data
Case: Molded plastic Terminal: Pure tin plated, lead free Polarity: Indicated by cathode band Packing: 12mm tape per EIA STD RS-481 Weight: 0.064 grams
TSM:BYG20D R3
BYG20D R3
