Texas Instruments Power Switch Ics - power distribution, Part #: TPS7H2201Y/EM | Integrated Circuit | DEX

Texas Instruments Power Switch Ics - power distribution, Part #: TPS7H2201Y/EM | Integrated Circuit | DEX

Regular price $530.82 USD
Regular price Sale price $530.82 USD
Sale Sold out
Shipping calculated at checkout.

Texas Instruments Power Switch Ics - power distribution, Part #: TPS7H2201Y/EM features: 1• Radiation performance: – Radiation hardness assurance (RHA) up to TID 100 krad(Si) – Single event latchup (SEL), single event burnout (SEB), and single event gate rupture (SEGR) immune to LET = 75 MeV-cm2 /mg – SEFI/SET characterized to LET = 75 MeV-cm2 /mg • Integrated single channel load switch • Input voltage range: 1.5 V to 7 V • Low on-resistance (RON) of 35-mΩ maximum at 25°C and VIN = 5 V • 6-A maximum continuous switch current • Low control input threshold enables use of 1.2-, 1.8-, 2.5-, and 3.3-V logic • Configurable rise time (soft start) • Reverse current protection • Programmable and internal current limiting (fast-trip) • Programmable fault timer (current limit and retry modes) • Thermal shutdown • Ceramic package with thermal pad

Applications: • Space satellite power management and distribution • Radiation hardened and tolerant power tree applications • Available in military (–55°C to 125°C) temperature range

The TPS7H2201-SP is a single channel load switch that provides configurable rise time to minimize inrush current and reverse current protection. The device contains a P-channel MOSFET that can operate over an input voltage range of 1.5 V to 7 V and can support a maximum continuous current of 6 A. The switch is controlled by an on and off input (EN), which is capable of interfacing directly with low-voltage control signals. The TPS7H2201-SP is available in a ceramic package with integrated thermal pad allowing for high power dissipation. The device is characterized for operation over the free-air temperature range of –55°C to 125°C.



TEX:TPS7H2201Y/EM

TPS7H2201Y/EM
