Xilinx Field Programmable Gate Array, Part #: XC3S100E-4CPG132I | FPGA | DEX

Xilinx Field Programmable Gate Array, Part #: XC3S100E-4CPG132I builds on the success of the earlier Spartan-3 family by increasing the amount of logic per I/O, significantly reducing the cost per logic cell. New features improve system performance and reduce the cost of configuration. These Spartan-3E FPGA enhancements, combined with advanced 90 nm process technology, deliver more functionality and bandwidth per dollar than was previously possible, setting new standards in the programmable logic industry. Because of their exceptionally low cost, Spartan-3E FPGAs are ideally suited to a wide range of consumer electronics applications, including broadband access, home networking, display/projection, and digital television equipment. The Spartan-3E family is a superior alternative to mask programmed ASICs. FPGAs avoid the high initial cost, the lengthy development cycles, and the inherent inflexibility of conventional ASICs. Also, FPGA programmability permits design upgrades in the field with no hardware replacement necessary, an impossibility with ASICs.

Features

• Very low cost, high-performance logic solution for high-volume, consumer-oriented applications • Proven advanced 90-nanometer process technology • Multi-voltage, multi-standard SelectIO™ interface pins • Up to 376 I/O pins or 156 differential signal pairs • LVCMOS, LVTTL, HSTL, and SSTL single-ended signal standards • 3.3V, 2.5V, 1.8V, 1.5V, and 1.2V signaling • 622+ Mb/s data transfer rate per I/O • True LVDS, RSDS, mini-LVDS, differential HSTL/SSTL differential I/O • Enhanced Double Data Rate (DDR) support • DDR SDRAM support up to 333 Mb/s

XLX:XC3S100E-4CPG132I

XC3S100E-4CPG132I
